Electrical Specifications
Connector Impedance | 50 Ohm | |
Operating Frequency Band | 0 – 6 GHz | |
RF Operating Voltage, maximum (vrms) | 1000.00 V | |
Outer Contact Resistance, maximum | 2.0 Mohm | |
Inner Contact Resistance, maximum | 3.0 Mohm | |
Insulation Resistance, minimum | 50000 Mohm | |
VSWR | <1.2 | |
Insertion Loss | Typical 0.05×√fdB | |
Mechanical Specifications
Mating Cycles | 500 Cycles | |
Recommended Mating Torque | 0.7-1.1 Nm | |
Environmental Specifications
Operating Temperature | -40°C to +125°C | |
Storage Temperature | -55°C to +125°C | |
Components
Name | Material | Plating |
Body | Brass | Tri-metal |
Inner Contact | Phosphor Copper | Silver |
Insulator | PTFE |
